CPU

• Supports 6th gen Intel® Core™ family/ Pentium / Celeron series processors for LGA 1151 socket
• Supports 7th gen Intel® Core™ family/ Pentium / Celeron series processors for LGA 1151 socket
• 5 Phase Thermal Design Power
• 100% Solid capacitor design

CHIPSET : Intel® H110 Express Chipset

GRAPHICS : Supports DirectX® 12

MEMORY

• Dual-channelDDR4 Memory architecture
• Supports DDR4 2400 non-ECC, Un-buffered SDRAM Memory
• 2 X 288-pin DDR4 DIMM socket
• Support up to 32 GB*

EXPANSION SLOT

• 1 X PCI Express X16 Gen 3.0 slot(s)
• 2 X PCI Express X 1 Gen 3.0slot(s)
• 1 X PCI slot(s)

STORAGE

• Support by H110 Express Chipset
• 4 X Serial ATAIII 6Gb/s

AUDIO

• 6-Channel HD audio CODEC
• Realtek ALC662
• Realtek ALC662 6-channel High Definition audio CODEC
• Meets performance requirements for Microsoft WLP 3.08 Vista premium and mobile PCs
• Six channel DAC supports 16/20/24-bit PCM format for 5.1 channel audio solution
• Emulation of 26 sound environments to enhance gaming experience
• Voice Cancellation and Key Shifting in Karaoke mode
• Compatible with Direct Sound 3D™, A3D™, I3DL2

LAN

• Realtek 8111GN Gigabit Fast Ethernet Controller
• Wake-On-LAN

USB

• 4 X USB 3.2 Gen 1x1 port(s) up to 5Gb/s
• 6 X USB2.0 port(s) Up to 480 Mb/s
• Back Panel 2 port(s)
• Onboard 4 port(s)

REAR PANEL I/O

• 1 X PS/2 Keyboard & PS/2 mouse connectors
• 1 X Serial port (COM)
• 1 X Audio port (Line Out/Line In/Mic In)
• 1 X RJ-45 port
• 1 X HDMI port(s)
• 1 X DVI-I port(s)
• 1 X D-Sub (VGA) port(s)
• 2 X USB 3.2 Gen 1x1 port(s)
• 2 X USB2.0 port(s)

CONNECTORS & HEADERS

• 1 X 24-pin ATX Power Supply connector
• 1 X 4-pin 12V Power connector
• 1 X 4-pin CPU_FAN connector
• 1 X 4-pin SYS_FAN connector
• 1 X Front Panel MIC/Speaker out header
• 1 X Front Panel switch/LED header
• 1 X USB 3.2 Gen 1x1 header
• Support additional 2 USB ports
• 2 X USB 2.0 header
• Support additional 4 USB ports
• 4 X SATA III 6Gb/s connector(s)
• 1 X CLR_CMOS header
• 1 X Serial port header (COM)
• 1 X Parallel port header (LPT)
• 1 X TPM header
• 1 X Chassis intrusion header

SYSTEM BIOS

• AMI BIOS with 64 MB SPI Flash ROM
• Supports M.I.B III Utility
• F7 hot key for boot up devices option
• Dual Display
• Support GUI UEFI BIOS
• Multi-Language BIOS

FORM FACTOR

• mATX Form Factor
• 244*210

OS SUPPORT

• Windows 7 32-bit
• Windows 7 64-bit
• Windows 8 32-bit
• Windows 8 64-bit
• Windows 8.1 32-bit
• Windows 8.1 64-bit
• Windows 10 64-bit

Windows 10 32-bit

• Intel 7th Generation CPUs support Windows 10 64bit only

CERTIFICATIONS : CE/FCC Certification

BUNDLED SOFTWARE : ECS Intelligent EZ Utility : eBLU, eDLU, eSF
