WIRELESS

Standards

• Wi-Fi 5
• IEEE 802.11ac/n/a 5 GHz
• IEEE 802.11n/b/g 2.4 GHz

WiFi Speeds

AC1200

• 5 GHz: 867 Mbps (802.11ac)
• 2.4 GHz: 300 Mbps (802.11n)

WiFi Range

• 3 Bedroom Houses
• 4× Fixed High-Performance Antennas
• Multiple antennas form a signal-boosting array to cover more directions and large areas

• Beamforming
• Concentrates wireless signal strength towards clients to expand WiFi range

WiFi Capacity

• Medium
• Dual-Band
• Allocate devices to different bands for optimal performance

• MU-MIMO
• Simultaneously communicates with multiple MU-MIMO clients

Working Modes

• Router Mode
• Access Point Mode

HARDWARE

Processor : Qualcomm CPU

Ethernet Ports

• 1× Gigabit WAN Port
• 4× Gigabit LAN Ports

Buttons

• WPS/Wi-Fi Button
• Power On/Off Button
• Reset Button

Power : 12 V ⎓ 1 A

SOFTWARE

WAN Types :

• Dynamic IP
• Static IP
• PPPoE
• PPTP
• L2TP

Dimensions (W×D×H) :

• 9.1 × 5.7 × 1.4 in
• (230 × 144 × 35 mm)

WiFi Reception Sensitivity:

• 5GHz:
• 11a 6Mbps:-93dBm；11a 54Mbps:-78dBm；
• 11ac HT20 mcs8:69dBm;11ac HT40 mcs9:-65dBm;
• 11ac HT80 mcs9:-62dBm;
• 2.4GHz:
• 11g 54Mbps:-78dBm;
• 11n HT20 mcs7:-74dBm;
• 11n HT40 mcs7:-71dbm；
