B660M GAMING X DDR4  Motherboard

Chipset: Intel® B660 Express Chipset

Memory: Support For DDR4 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) /3200/3000/2933/2666/2400/2133 MHz Memory Modules 4 X DDR DIMM Sockets Supporting Up To 128 GB (32 GB Single DIMM Capacity) Of System Memory Dual Channel Memory Architecture Support For ECC Un-Buffered DIMM 1Rx8/2Rx8 Memory Modules (Operate In Non-ECC Mode) Support For Non-ECC Un-Buffered DIMM 1Rx8/2Rx8/1Rx16 Memory Modules Support For Extreme Memory Profile (XMP) Memory Modules

Graphics: Integrated Graphics Processor-Intel® HD Graphics Support: 1 X HDMI Port, Supporting A Maximum Resolution Of 4096x2160@60 Hz Support For HDMI 2.1 Version And HDCP 2.3. Support Native HDMI 2.1 TMDS Compatible Ports. 1 X DisplayPort, Supporting A Maximum Resolution Of 4096x2304@60 Hz * Support For DisplayPort 1.2 Version And HDCP 2.3

LAN: 2.5GbE LAN Chip (2.5 Gbps/1 Gbps/100 Mbps)

Internal I/O Ports: 1 X 24-Pin ATX Main Power Connector
                             1 X 8-Pin ATX 12V Power Connector
                             1 X CPU Fan Header
                             3 X System Fan Headers
                             2 X Addressable LED Strip Headers
                             2 X RGB LED Strip Headers
                             2 X M.2 Socket 3 Connectors
                             4 X SATA 6Gb/S Connectors
                             1 X Front Panel Header
                             1 X Front Panel Audio Header
                             1 X USB 3.2 Gen 1 Header
                             2 X USB 2.0/1.1 Headers
                             1 X S/PDIF Out Header
                             2 X Thunderbolt™ Add-In Card Connectors
                             1 X Trusted Platform Module Header (For The GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 Module Only)
                             1 X Serial Port Header
                             1 X Reset Button
                             1 X Q-Flash Plus Button
                             1 X Reset Jumper
                             1 X Clear CMOS Jumper

WiFi: Wifi 2.5GbE LAN Chip (2.5 Gbps/1 Gbps/100 Mbps)

Form Factor: Micro ATX Form Factor; 24.4cm X 24.4cm

BIOS: 1 X 256 Mbit Flash

Use Of Licensed: AMI UEFI BIOS
                              PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Warranty: 3 Year Warranty
